Authenticating Salesforce CLI with SSO on Ubuntu
Dumb challenge that I decided to take on: I’ve got Ubuntu 22.04 VM running my
sfCLI. The CLI authentication launches a local browser (or, requires a Salesforce admin to allow JWT auth). But my web browser lives on my local Windows desktop. I authenticate to Salesforce via our corporate workspace SSO. How can I authenticate my CLI?
It sounds like a simple remote connection issue, but the modern Salesforce CLI architecture has some strict guardrails around interactive logins. I put this write-up together to track the clever hacks that Claude and Gemini came up with that failed, and the method I could have used from the beginning.
The Environment & Constraints
Our target state required meeting three distinct conditions:
- CLI on Ubuntu: The Ubuntu VM has no graphical user interface (GUI) and no native web browser installed.
- SSO Login: Standard username/password logins are blocked by corporate policy; authentication must flow through the identity provider, and that uses a browser that must be running on a corporate-managed device.
- Local Isolation: The local Windows host cannot have the Salesforce CLI installed, preventing us from simply authenticating locally and exporting the session.
What I Tried (and Why it Failed)
When you run a standard sf org login web command on a headless machine, the CLI hangs. It searches the Linux environment for a default browser utility to launch the SSO page, finds nothing, and gets stuck in an infinite retry loop without printing a fallback URL.
I tried a few creative ways to cheat this validation mechanism (Claude and Gemini thought of them):
The Fake “Firefox” Executable
I thought I could trick the CLI into thinking it had a real browser. I created a local directory, added it to the front of the system PATH, and created a dummy bash script named firefox. The script was incredibly simple — it just accepted the URL passed by the CLI and echoed it out to the terminal:
1
2
3
4
5
6
7
8
9
10
11
12
# 1. Create a local bin folder if you haven't already
mkdir -p ~/bin
# 2. Create a fake "firefox" executable that just echoes the login URL
echo -e '#!/bin/bash\necho -e "\n=== COPY THIS URL ===\n$1\n=====================\n"' > ~/bin/firefox
chmod +x ~/bin/firefox
# 3. Add our local bin folder to the FRONT of your session's execution path
export PATH=~/bin:$PATH
# 4. Force the CLI to launch what it thinks is your firefox browser
sf org login web --instance-url $INSTANCE_URL --alias f5-org --set-default --browser firefox
I executed the command with the --browser firefox flag. In theory, it should have printed the login link. Instead, the CLI threw a hard CannotOpenBrowserError. Under the hood, the modern Node.js core of the CLI doesn’t just look for a string in your PATH; it actively probes the operating system registry to verify a functional graphical desktop application is registered. No GUI means an immediate crash.
The Container Mode Flag
Next, I tried forcing the CLI into headless mode using environment variables: SF_CONTAINER_MODE=true.
This bypassed the browser validation checks, but hit a hard security gate built into the compiler, resulting in this flat error:
1
Error (SfError): "org login web" isn't supported when authorizing in a headless environment.
Salesforce CLI explicitly blocks the web login flow in container modes because opening a local listening server on port 1717 to catch browser redirects is considered an insecure pattern on headless cloud environments.
Port Forwarding
I really thought this would work. Here’s what you do:
- Set up a port forwarding from your Windows VM (port 1717) to your Linux VM (port 1717). In PowerShell:
1
ssh -L 1717:localhost:1717 ubuntu@192.168.1.153
- run
sf org login webfrom the Ubuntu VM, and see if you can get the URL that it would call with a browser. In Bash:
1
sf org login web --instance-url $INSTANCE_URL --alias f5-org --set-default --browser firefox
- A URL should appear, find a way to open it on the Windows VM, and when it redirects to the callback URL of
localhost:1717/xxx, the Windows browser will call localhost, get forwarded to the Linux VM, and the process listening on the Linux VM would respond.
Unfortunately, this fails. In step #2, the URL that would be called by the CLI is not printed to the user. Trying to catch it failed (see my first trick). And in step #3, the process was not listening or expecting for any traffic on tcp/1717 because launching a browser never worked.
The Breakthrough: Sfdx-URL Auth Flow
What is this? At a fundamental level, the difference comes down to how the authentication secret is generated and captured.
sf org login --help shows us we have options other than a browser-based login flow:
1
2
3
4
5
6
7
8
9
10
11
ubuntu@ubuntu-Virtual-Machine:~$ sf org login --help
Authorize an org for use with Salesforce CLI.
USAGE
$ sf org login COMMAND
COMMANDS
org login access-token Authorize an org using an existing Salesforce access token.
org login jwt Log in to a Salesforce org using a JSON web token (JWT).
org login sfdx-url Authorize an org using a Salesforce DX authorization URL stored in a file or through standard input (stdin).
org login web Log in to a Salesforce org using the web server flow.
I didn’t try the first method (access-token) because even if I found my access token via a web login, access tokens expire quickly. This would have been shortlived. The second method (jwt) requires a Salesforce admin to set up an external app. But this third option (sfdx-url) was the key.
web is an interactive protocol designed for a human sitting at a desktop; sfdx-url is a static file ingestion engine designed for automation, scripts, and headless servers.
1. Web Login (sf org login web)
When you execute this command, the CLI assumes it has full access to a local desktop environment.
- The Listener: The CLI spins up a temporary, lightweight HTTP web server on your local machine, listening out on
http://localhost:1717/OauthRedirect. - The Handshake: It communicates with your OS to launch your default browser, pointing it to your Salesforce login or SSO landing page.
- The Interception: After you successfully pass SSO and click “Allow”, Salesforce redirects the browser to
localhost:1717. Your local CLI server catches that incoming HTTP request, extracts the authorization code, exchanges it under the hood for an active refresh token, and kills the temporary web server.
🛑 Why it breaks headlessly: If there is no desktop GUI registry to open a browser, the command blocks indefinitely waiting for a browser application process to return a success status. If you try to force it into container mode, the compiler explicitly blocks it because exposing port 1717 on an automated runner is an unnecessary security risk.
2. SFDX-URL Login (sf org login sfdx-url)
This flow drops the entire interactive browser dance and the local listening web server. It treats authentication exactly like importing an SSH key or an API token.
Instead of generating a session, it restores one. It reads a specialized URL string from a file using the custom force:// protocol handler scheme:
1
force://<clientId>:<clientSecret>:<refreshToken>@<instanceUrl>
When you pass this file to the CLI:
- The CLI bypasses all browser or OS validation steps entirely.
- It reads the string, grabs the refreshToken, and shoots a direct, headless backend API call out to the
to verify the token is valid. - Once Salesforce verifies it, the CLI saves the connection to its local secure storage (~/.sfdx/ or ~/.local/share/sf/).
This is the standard enterprise method for CI/CD pipelines. You generate a token once, inject that raw force://… string into your pipeline’s protected environment variables (like GitHub Encrypted Secrets), echo it to a temporary file during a build run, and authenticate the runner instantly with zero human eyes or clicks required.
Summary of web vs sfdx-url login
| Feature | web login |
sfdx-url |
|---|---|---|
| Primary Use Case | Local day-to-day development on a laptop/desktop. | CI/CD pipelines (GitHub Actions, Jenkins) and headless VMs. |
| Mechanism | Spawns a local web server socket and triggers an OS browser. | Reads a pre-constructed token string straight from a text file. |
| Human Needed? | Yes. Requires real-time UI interaction to input credentials. | No. Fully automated and scriptable. |
| Network Dependency | Requires a local port (1717) to receive a callback loop. |
Needs only standard outbound HTTPS to validate the token against Salesforce. |
| Token Type | Generates a brand-new Refresh Token dynamic session. | Imports an existing Refresh Token generated elsewhere. |
Conclusion: How to use sfdx-url auth flow
Manually request the token via the local Windows browser with a specially constructed URL. The redirect to a callback URL will fail, but grab the refresh token from the URL. Create an auth file for CLI auth.
| Step | Action | Description |
|---|---|---|
| 1 | Construct OAuth URL | For me, this was the URL: https://(instance_url)/services/oauth2/authorize?response_type=token&client_id=PlatformCLI&redirect_uri=http://localhost:1717/OauthRedirect |
| 2 | Browser SSO | Pasting that URL into the Windows desktop browser allowed the user to complete their corporate workspace SSO and hit Allow. |
| 3 | Capture Redirect | The browser redirected to an expected “Site Cannot Be Reached” error page on localhost:1717. We copied the URL straight out of the address bar, which now contained the secret refresh_token. |
| 4 | Format Token File | On the Ubuntu VM, create a custom text file (sfdx_auth.txt) matching the exact URI schema the CLI expects: force://PlatformCLI::<refreshToken>@<instance_url> |
| 5 | Import to CLI | Execute sf org login sfdx-url --sfdx-url-file sfdx_auth.txt to authenticate with this file, then remove the file. |
Disclosure and The Post-Logout Surprise
One interesting takeaway happened at the very end of testing. I ran sf org logout to test cleaning up the environment, and then ran the sfdx-url login command again using the exact same text file. It worked. I expected that the refresh token would be revoked at client logout and I’d be forced to login via browser, but I was wrong.
So I think that sf org logout does not revoke your refresh token on the server. Remember: guard this refresh token like a password and don’t persist it on disk.
So, disclosure: I’m not sure if this is a blessed approach by corporate IT, so check with your policies. But it’s a documented method for authenticating to Salesforce for continuous integration (CI) environments.
